62
7
ENTRETIENSTÛV 21
.5 COMPONENTS REPLACEMENT
GLASS AND SLIDES
1615
1413
8mm
T20
After disassembly, follow these steps:
Step 13 Using an 8 mm open-end wrench,
unscrew the damper cover.
Step 14 Close the door and remove the
damper panel cover.
Step 15 Using the fireplace handle
remove the keys freeing the innersprings.
Put them on the left and right side.
Step 16 Unscrew and remove the glass
pane.
