63
7
ENTRETIENSTÛV 21
.5 COMPONENTS REPLACEMENT
212019
1817
T20
T20
MODÈLE DIMENSIONS
21-85 554 mm x 692 mm
21-95 634 mm x 790 mm
21-105 419 mm x 892 mm
21-125 554 mm x 1090 mm
Step 17 Remove the (damaged) glass.
Stûv recommends the use of original
replacement parts.
The glass must be made of 4 mm ceramic
and be able to withstand high temperatures.
Step 18 Using a Torx 20 bit remove 2
screws from each side.
Step 19 Remove the sliding door.
Step 20 Move the center rail of the slide
to access the four screws, then unscrew.
Step 21 Remove the (damaged) slide.
