Sullivan-Palatek 40D - 30 D7, H30 D7, Hh30 D7

10 SPECIFICATIONS
2.1.5 30D7, H30D7, HH30D7
COMPRESSOR DATA 30D7 H30D7 HH30D7
Capacity acfm 115 110 105
Pressure @ Full Load psig (bar) 125 (8.6) 150 (10.3) 175 (12.1)
Minimum Pressure psig (bar) 60 (4.1) 70 (4.8) 70 (4.8)
Motor Output (60 Hz) hp (kW) 30 (22.4) 30 (22.4) 30 (22.4)
Motor Speed rpm 3,550 3,550 3,550
Motor Output @ Full Load hp (kW) 30 (22.4) 30 (22.4) 33 (24.6)
Motor Output @ 100 psig hp (kW) 28 (20.9)
Driven Rotor Coupling Direct Direct Direct
Drive Ratio 1 1 1
Rotor Diameter mm 108 108 108
COOLING DATA (AIR-COOLED) 30D7 H30D7 HH30D7
Fan Airow cfm 2,600 2,600 2,600
Maximum Duct Loss inH
2
O 0.25 0.25 0.25
Aercooler Approach °F (°C) 15 (-9) 15 (-9) 15 (-9)
Heat Rejection btu/hr (kW) 71,600 (21.0) 71,600 (21.0) 71,600 (21.0)
Fluid Capacity gallons (liters) 3 (11) 3 (11) 3 (11)
COOLING DATA (WATER-COOLED) 30D7 H30D7 HH30D7
Water Flow with 60°F Water gpm (L/min) 3 (11.4) 3 (11.4) 3 (11.4)
Water Flow with 70°F Water gpm (L/min) 3.7 (14.0) 3.7 (14.0) 3.7 (14.0)
Water Flow with 80°F Water gpm (L/min) 5 (18.9) 5 (18.9) 5 (18.9)
Maximum Water Temperature °F (°C) 85 (29) 85 (29) 85 (29)
Water Connection In-Out NPT 3/4 - 3/4 3/4 - 3/4 3/4 - 3/4
SOUND DATA 30D7 H30D7 HH30D7
Air-Cooled (Open) dba @ 1m 85 85 85
Air-Cooled (Enclosed) dba @ 1m 75 75 75
Water-Cooled (Open) dba @ 1m 80 80 80
Water-Cooled (Enclosed) dba @ 1m 80 80 80
DISCHARGE PIPING 30D7 H30D7 HH30D7
Air-Cooled (Base-Mounted) NPT 1 1 1
Water-Cooled (Base-Mounted) NPT 1-1/2 1-1/2 1-1/2
Tank-Mounted (Tank End) NPT 2 2 2
ELECTRICAL DATA 30D7 H30D7 HH30D7
Motor FLA @ 575V amps 28.0 28 28.0
Motor FLA @ 460V amps 35.0 35.0 35.0
Motor FLA @ 230V amps 70.0 70.0 70.0
Motor FLA @ 208V amps 77.4 77.4 77.4
Motor FLA @ 200V amps 89.0 89 89.0
Starter Enclosure Rating NEMA 1 1 1
Control Voltage volts 110 110 110
Motor Enclosure NEMA ODP ODP ODP
Motor Insulation Class NEMA F F F
Motor Service Factor NEMA 1.25 1.25 1.25
Motor Maximum Starts/Hour 4 4 4
