2.25
TYP
42.0015.50
73.00
5.00
DRAIN
2" NPT PORT
BOTH ENDS
1/4" NPT
MOIST. DRAIN
26.00
40.002.00
32.20
14.50 44.00
26.00
10.00
DRAIN
1.22
DRAIN
19.00
33.50
21.38
24.27
4X
.88 X 1.50
MOUTNING SLOTS
SAFETY
PRESSURE RELIEF
VALVE
RECEIVER
PRESSURE GAUGE
DWG, ASSY 200G REC EB15/20
GENERAL ARRANGEMENT
AS812-200
00
04/12/12
DJW
2 OF 2
1:8
REVISIONS
REV.
DESCRIPTION
DATE
APPROVED
00
RELEASED
04/20/12
DJW/GLB
D
C
1
3
4
5
A
B
C
D
E
F
5
3
2
1
F
E
B
A
4
2
3RD ANGLE
PROJECTION
1201 West US Highway 20, Michigan City IN 46360
1-800-438-6203
SHEET
SCALE:
TOLERANCES AS FOLLOWS:
REV
DESCRIPTION
THIS DRAWING AND ALL INFORMATION THEREIN IS THE PROPERTY OF SULLIVAN-PALATEK, INC. IS CONFIDENTIAL AND MUST NOT BE MADE PUBLIC OR COPIED.
WWW.SULLIVANPALATEK.COM
SULLIVAN-PALATEK
CHECKED BY:
DATE:
DATE:
DRAWN BY:
FIRST USED ON:
ANGLES: + OR - 1/2 DEG.
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE NOTED
X.XXX + OR - 0.005
X.XX + OR - 0.020
DECIMAL: X.X + OR - 0.050
MATERIAL:
IT IS LOANED SUBJECT TO RETURN UPON DEMAND, IS NOT TO BE USED DIRECTLY OR INDIRECTLY IN ANYWAY DETRIMENTAL TO SULLIVAN-PALATEK'S INTEREST.
DRAWING NO:
D
SIZE
