Sullivan-Palatek 40D - 40 D, H40 D, Hh40 D

11SPECIFICATIONS
2.1.6 40D, H40D, HH40D
COMPRESSOR DATA 40D H40D HH40D
Capacity acfm 166 115 110
Pressure @ Full Load psig (bar) 125 (8.6) 150 (10.3) 175 (12.1)
Minimum Pressure psig (bar) 60 (4.1) 70 (4.8) 70 (4.8)
Motor Output (60 Hz) hp (kW) 40 (29.8) 40 (29.8) 40 (29.8)
Motor Speed rpm 3,550 3,550 3,550
Motor Output @ Full Load hp (kW) 47 (35.0) 41 (30.6) 43 (32.1)
Motor Output @ 100 psig hp (kW) 42 (31.3)
Driven Rotor Coupling Direct Direct Direct
Drive Ratio 1 1 1
Rotor Diameter mm 108 108 108
COOLING DATA (AIR-COOLED) 40D H40D HH40D
Fan Airow cfm 3,500 3,500 3,500
Maximum Duct Loss inH
2
O 0.25 0.25 0.25
Aercooler Approach °F (°C) 15 (-9) 15 (-9) 15 (-9)
Heat Rejection btu/hr (kW) 106,300 (31.1) 106,300 (31.1) 106,300 (31.1)
Fluid Capacity gallons (liters) 3.5 (13) 3.5 (13) 3.5 (13)
COOLING DATA (WATER-COOLED) 40D H40D HH40D
Water Flow with 60°F Water gpm (L/min) 4.5 (17.0) 4.5 (17.0) 4.5 (17.0)
Water Flow with 70°F Water gpm (L/min) 5.8 (21.0) 5.8 (21.0) 5.8 (21.0)
Water Flow with 80°F Water gpm (L/min) 7.6 (28.8) 7.6 (28.8) 7.6 (28.8)
Maximum Water Temperature °F (°C) 85 (29) 85 (29) 85 (29)
Water Connection In-Out NPT 3/4 - 3/4 3/4 - 3/4 3/4 - 3/4
SOUND DATA 40D H40D HH40D
Air-Cooled (Open) dba @ 1m 85 85 85
Air-Cooled (Enclosed) dba @ 1m 80 80 80
Water-Cooled (Open) dba @ 1m 80 80 80
Water-Cooled (Enclosed) dba @ 1m 80 80 80
DISCHARGE PIPING 40D H40D HH40D
Air-Cooled (Base-Mounted) NPT 1-1/4 1-1/4 1-1/4
Water-Cooled (Base-Mounted) NPT 1-1/2 1-1/2 1-1/2
Tank-Mounted (Tank End) NPT 2 2 2
ELECTRICAL DATA 40D H40D HH40D
Motor FLA @ 575V amps 36.0 36 36.0
Motor FLA @ 460V amps 45.0 45.0 45.0
Motor FLA @ 230V amps 90.0 90.0 90.0
Motor FLA @ 208V amps 99.5 99.5 99.5
Motor FLA @ 200V amps 102.0 102 102.0
Starter Enclosure Rating NEMA 1 1 1
Control Voltage volts 110 110 110
Motor Enclosure NEMA ODP ODP ODP
Motor Insulation Class NEMA F F F
Motor Service Factor NEMA 1.25 1.25 1.25
Motor Maximum Starts/Hour 4 4 4
