2.9 DIMENSIONS–HORIZONTAL RECEIVER (120 GALLON)
2.25 TYP
42.0012.88
3.63
DRAIN
67.75
1/4" NPT
MOIST. DRAIN
2" NPT PORT
BOTH ENDS
26.00 40.00
44.00
2.00
11.88
26.46
21.38
24.27
6.13
DRAIN
18.25 21.25
1.22
DRAIN
26.50
16.00
4X
.88 X 1.50
MOUNTING SLOTS
SAFETY
PRESSURE RELIEF
VALVE
RECEIVER
PRESSURE GAUGE
DWG, ASSY 120G REC EB15/20
GENERAL ARRANGEMENT
AS812-120
00
04/10/12
DJW
2 OF 2
1:8
