8.11 AIR INLET CONTROLS (15–30HP)
5
4
8
1
8
10
6
MICRO ONLY
STANDARD
11
A
AA
B
BB
BB
AA
C
9
CC
CC
13
7
2
12
3
8
12
NTS
1 OF 1
DJW
03/13/12
03
AS820-005
PALATEK 108 INLET CONRTOLS
DRAWING, ASSEMBLY 15-30HP
SOLENOID P/N CHANGES FOR >145PSI DESIGNS
(1) 40529-011 & (2) 00901161 0005 TO BE USED.
VFD DESIGNS:
CONTROL PRESSURE REGULATOR NOT USED.
(1) 95510-004 & (1) 91557-044 NOT USED FROM LINE "C".
REVISIONS
REV.
DESCRIPTION
DATE
APPROVED
00
RELEASED
03/13/12
DJW/GLB
01
UPDATE PER TESTING-PROPER UNLOAD DESIGN
6/23/2015
DJW/GET
02
UPDATED TO REMOVE BOTTOM ATMOSPHERE VENT
9/11/2015
TBM/DJW
03
UPDATED TO ADD RECIRCULATION LOOP
3/25/2016
TBM/RRM
TUBING LEGEND
A
FROM TANK LID (DRY SIDE)
B
TO ASP SWITCH
C
FROM CONTROL PRESSURE REGULATOR
INTERNAL TO CONTROLS
AA
BLOWDOWN LINE
BB
ATMOSHPERIC VENT LINE
CC
RECIRCULATION LINE
ITEM #
PART NUMBER
DESCRIPTION
QTY.
1 00906058 0004
NIPPLE, HEX PIPE 1/4 X 1/4
1
2
03001-063
ORIFICE, .063 1/4" M X F
1
3 05019730 0005
VALVE, CHECK 1/4NPT
1
4
09790-007E
VALVE, INTAKE 3"OD 90DEG.
1
5
40529-010
VALVE,SOLENOID 2-W NO120V
1
6
91550-064
CONN, NT 3/8 X1/4''FPT
1
7
91553-044
CONN, NT 1/4 X 1/4 MPT
1
8
91557-044
ELBOW, 90 NT 1/4 X 1/4 M
3
9
91557-064
ELBOW, 90 NT 3/8 X 1/4 M
2
10
91564-044
TEE, MALE RUN 1/4NT X 1/4
1
11
94561-002
PLUG, PIPE 1/4" SQUARE HD
1
12
95510-004
TEE, .250 MNPT X FNPT X FNPT BRASS
2
13
96399-004
ELBOW, 1/4" MNPT X MNPT STEEL
1
A
B
C
D
E
F
F
E
D
C
B
A
5
4
3
2
1
1
2
3
4
5
SHEET
SCALE:
TOLERANCES AS FOLLOWS:
REV
DESCRIPTION
THIS DRAWING AND ALL INFORMATION THEREIN IS THE PROPERTY OF SULLIVAN-PALATEK, INC. IS CONFIDENTIAL AND MUST NOT BE MADE PUBLIC OR COPIED.
1201 West US Highway 20, Michigan City IN 46360
WWW.SULLIVANPALATEK.COM 1-800-438-6203
SULLIVAN-PALATEK
CHECKED BY:
DATE:
DATE:
DRAWN BY:
FIRST USED ON:
ANGLES: + OR - 1/2 DEG.
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE NOTED
X.XXX + OR - 0.005
X.XX + OR - 0.020
DECIMAL: X.X + OR - 0.050
MATERIAL:
IT IS LOANED SUBJECT TO RETURN UPON DEMAND, IS NOT TO BE USED DIRECTLY OR INDIRECTLY IN ANYWAY DETRIMENTAL TO SULLIVAN-PALATEK'S INTEREST.
DRAWING NO:
C
SIZE
MICRO ONLY
STANDARD
A
AA
B
BB
BB
AA
C
CC
CC
1
12
3
9
11
13
9
7
13
2
14
4
8
6
5
10
NTS
1 OF 1
DJW
03/13/12
03
AS820-003
PALATEK 108 INLET CONRTOLS
DRAWING, ASSEMBLY
VFD DESIGNS: CONTROL PRESSURE REGULATOR NOT USED.
(1) 95510-004 & (1) 91557-044 NOT USED FROM LINE "C".
REVISIONS
REV.
DESCRIPTION
DATE
APPROVED
00
RELEASED
03/13/12
DJW/GLB
01
UPDATE PER TESTING PROPER UNLOAD DESIGN
6/24/2015
DJW/GLB
02
UPDATED TO REMOVE BOTTOM ATMOSPHERE VENT
9/11/2015
TBM/DJW
03
UPDATED TO ADD RECIRCULATION LOOP
4/4/2016
TBM/RRM
TUBING LEGEND
A
B
TO ASP SWITCH
C
FROM CONTROL PRESSURE REGULATOR
INTERNAL TO CONTROLS
AA
BLOWDOWN LINE
BB
ATMOSHPERIC VENT LINE
CC
RECIRCULATION LINE
ITEM #
PART NUMBER
DESCRIPTION
QTY
1 00901161 0005
BUSHING, RDC GALV 1/2"X1/4"
2
2 00906058 0004
NIPPLE, HEX PIPE 1/4 X 1/4
1
3
03001-063
ORIFICE, .063 1/4" M X F
1
4 05019730 0005
VALVE, CHECK 1/4NPT
1
5
09790-007E
VALVE, INTAKE 3"OD 90DEG.
1
6
40529-011
VALVE,SOLENOID 2-W NO120V
1
7
91550-064
CONN, NT 3/8 X1/4''FPT
1
8
91553-044
CONN, NT 1/4 X 1/4 MPT
1
9
91557-044
ELBOW, 90 NT 1/4 X 1/4 M
3
10
91557-064
ELBOW, 90 NT 3/8 X 1/4 M
2
11
91564-044
TEE, MALE RUN 1/4NT X 1/4
1
12
94561-002
PLUG, PIPE 1/4" SQUARE HD
1
13
95510-004
TEE, .250 MNPT X FNPT X FNPT BRASS
2
14
96399-004
ELBOW, 1/4" MNPT X MNPT STEEL
1
A
B
C
D
E
F
F
E
D
C
B
A
5
4
3
2
1
1
2
3
4
5
SHEET
SCALE:
TOLERANCES AS FOLLOWS:
REV
DESCRIPTION
THIS DRAWING AND ALL INFORMATION THEREIN IS THE PROPERTY OF SULLIVAN-PALATEK, INC. IS CONFIDENTIAL AND MUST NOT BE MADE PUBLIC OR COPIED.
1201 West US Highway 20, Michigan City IN 46360
WWW.SULLIVANPALATEK.COM 1-800-438-6203
SULLIVAN-PALATEK
CHECKED BY:
DATE:
DATE:
DRAWN BY:
FIRST USED ON:
ANGLES: + OR - 1/2 DEG.
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE NOTED
X.XXX + OR - 0.005
X.XX + OR - 0.020
DECIMAL: X.X + OR - 0.050
MATERIAL:
IT IS LOANED SUBJECT TO RETURN UPON DEMAND, IS NOT TO BE USED DIRECTLY OR INDIRECTLY IN ANYWAY DETRIMENTAL TO SULLIVAN-PALATEK'S INTEREST.
DRAWING NO:
C
SIZE
