77
AS805-030D7H-TE AIR INLET ASSEMBLY (15–30HP)
ITEM PART NUMBER DESCRIPTION QTY
1* 09790-007E VALVE, INTAKE 3"OD 90° 1
2 00077-253 HUMP, HOSE 2.50 X 3.00 1
3 92320-128 CLAMP, HOSE 4-1/2" 1
4* 28174-060 FILTER, AIR - 6'' OD 1
5 92320-080 CLAMP, HOSE 4-1/2" 1
6 00131-060 BAND, MTG. 6.0 1
11 00216-045 BRACKET, AIR FILTER PH 1
12 93115-012 BOLT, WHIZ 5/16-18 X 1" 3
13 93165-003 NUT, WHIZ HEX 5/16-18 3
14 90660-344 O-RING, VITON 1
16 93115-034 BOLT, WHIZ 1/2-13 X 1 1/2 4
17 94561-002 PLUG, PIPE 1/4" SQUARE HD 1
*See 8.3 Recommended Spare Parts List on page 61
