73
AS802-01540D PNEUMATIC CONTROLS ASSEMBLY (15–40HP)
ITEM PART NUMBER DESCRIPTION QTY
1* CONSULT FACTORY STARTER, 230/460/575V 1
2 09344-001 SWITCH, PRESSURE ANTI-STR 1
3 09344-003 SWITCH, PRESSURE ROP 1
5 93115-013 BOLT, WHIZ 3/8-16 1.0 GR5 2
6 93165-004 NUT, WHIZ HEX 3/8-16 2
7 93115-387 BOLT, WHIZ 1/4"-20 X 1/2" 2
8 93165-002 NUT, WHIZ, 1/4-20 GR5 PLT 2
9 91557-064 ELBOW, 90 NT 3/8 X 1/4 M 1
10 91557-044 ELBOW, 90 NT 1/4 X 1/4 M 1
11 00347-004 LIGHT ASS'Y, "POWER ON" 1
12 B00701-780 SWITCH, ASY 3 POS MAINT 1
13 00735-120 HOURMETER, 2"DIA 60HZ 1
14 91564-042 TEE, MALE RUN 1/4NT X 1/8 1
15 91557-042 ELBOW, 90 NT 1/4 X 1/8 M 1
16 09175-001 GAUGE, DELTA-P 0-15 PSID 1
17 09175-030 GAUGE, DELTA-P 0-30 PSID 1
18 08312-026M GAUGE, TEMP 2.5" 6FT CAP 1
19 09174-325 GAUGE, PRES.(LIQ-FIL)2.5" 2
20 91550-042 CONN, NT 1/4 X 1/8 FPT 4
21 91550-044 CONN, NT 1/4 X 1/4 FPT 2
22 00944-007 PANEL, GAUGE (5-HOLE) 1
23 08378-061 DECAL, 5 GAUGE PANEL 1
24 09345-006 SWITCH, PRESSURE NEMA 1, 125 PSI 1
09345-012 SWITCH, PRESSURE NEMA 1, 150 PSI (H)/175 PSI (HH) 1
09345-008 SWITCH, PRESSURE NEMA 4, 125 PSI 1
09345-004 SWITCH, PRESSURE NEMA 4, 150 PSI (H)/175 PSI (HH) 1
09345-006N4X SWITCH, PRESSURE NEMA 4X, 125 PSI 1
09345-024 SWITCH, PRESSURE NEMA 4X, 150 PSI (H)/175 PSI (HH) 1
See 8.11 Air Inlet Controls (15–30hp) on page 78, and 8.13 Air Inlet Controls (40hp) on page 82
