87
AS803-030D7H-TE DISCHARGE ASSEMBLY (20–30HP)
ITEM PART NUMBER DESCRIPTION QTY
1 03448-028 TANK, SUMP/SEPARATOR 10" 1
2 00633-001 GASKET, DISCHARGE 1
3 09610-001 VALVE, MPC (1-1/4") 1
4 91176-020 NIPPLE, CL BLK SCH80 1.25 1
5 08000-019 ELEMENT, SEPARATOR 15-30 HP 1
6 92773-038 STUD, B7 5/16-18 X 1-1/2'' 12
7 90165-003 NUT, HEX 5/16-18 12
8 95510-004 TEE, .250 MNPT X FNPT X FNPT BRASS 2
9 92469-200 NIPPLE, YEL BRASS 1/4 X 6 1
10 91160-017 BUSHING, 1-1/4 X 1 1
11 03100-008 VALVE, SAFETY RELIEF .50 MNPT - 200PSIG 1
12 09661-002 REGULATOR, 1/4" FNPT 1
13 96363-161 CONN, CMS 1 X 1 1
14 03286-003 FITTING, SIPHON 1/4" MNPT X 1/4" TUBE 1
15 91557-064 ELBOW, 90 NT 3/8 X 1/4 M 2
16 91553-044 CONN, NT 1/4 X 1/4 MPT 1
17 91564-042 TEE, MALE RUN 1/4NT X 1/8 2
18 09602-024 TUBE, OIL TOP RTN 15-30HP 1
19 09602-025 TUBE, SCAV BTM RTN 15-30HP 1
20 96390-042 ELBOW, CMS 1/4T X 1/8 MPT 1
21 17254-016 SIGHT GLASS, 1.00 MNPT 1
22 07255-016 CAP, VENTED 1
23 96399-004 ELBOW, 1/4" MNPT X MNPT STEEL 1
24 95784-004 VALVE, DRAIN 1/4" F X F 1
25 94561-002 PLUG, PIPE 1/4" SQUARE HD 1
26 09616-055 TUBE, 1" MPCV-AC 25D/30D7 1
27 96390-161 ELBOW, CMS 1 X 1 1
28 93115-013 BOLT, WHIZ 3/8-16 1.0 GR5 2
29 93165-004 NUT, WHIZ HEX 3/8-16 2
30 B29349-064 KIT, OIL RTRN SIGHTGLASS 1
31 96363-044 CONN, CMS 1/4T X 1/4MPT 1
32 09349-001 SIGHTGLASS, OIL RETURN 1
33 18577-001 INSERT 1
34 03001-041 ORIFICE, INSERT 0.041 1
35 00023-001 ADAPTER, OIL RTN SIGHTGLASS 1
36 95550-042 CONN, CFS 1/4T X 1/8 FPT 1
