91
AS804-015DT-TE COOLING & LUBRICATION ASSEMBLY, AIR-COOLED (15-25HP)
ITEM PART NUMBER DESCRIPTION QTY
1 07711-202 COOLER, OIL/A.C. 15-30D7 1
2 13400-104 SHROUD, FAN 15-30D7 1
3 03216-104 GUARD,FAN 15-30HP 1
4 93115-002 BOLT, WHIZ 1/4"-20 X 1/2" 16
5 08207-055 HOUSING, BY-PASS 1
6 90659-121 O-RING, VITON 2
7 09505-006 VALVE, THERMOSTAT 155/185 1
8 90115-093 BOLT, HH 3/8-16 X 3 2
9 80120-010 CONN, CMS ORB 5/8 X .875M 3
10 00851-001 HUB, FAN 1 3/8 BORE X 1" 15/20/25/30 HP 1
00851-002 HUB, FAN 1 3/8 BORE X 1" 25D4 HP 1
11 08080-016 FAN, 15 HP 1
08080-021 FAN, 20 HP 1
08080-025 FAN, 25D HP 1
08080-018 FAN, 25D4 HP 1
12 92224-047 BOLT, SOC 1/4-20 X 3/4 4
13 90947-252 KEY, SQ 5/16 X 3/4 1
14 90502-063 BOLT, SOC 1/4-20 X 3/4 1
15 93165-002 NUT, WHIZ 1/4"-20 10
16 09612-016 TUBE, THERMO VALVE TO AIR END 150 1
17 09612-026 TUBE, 5/8" SUMP-TV 25D4 1
18 80120-012 CONN, CMS ORB 3/4 X 1.06M 1
