2-10
5: Insert the fiber into the splicer.
Open the cover. Take out the fiber and fiber offcut from the cleaver.
4:
1. Do not re-clean the fiber after cleaving.
2. To avoid damaging or contaminating the delicate fiber ends, insert each
fiber immediately after preparation.
3. Glass-fiber fragments are extremely sharp. Handle with care.
Caution
Bare fiber
Cleave
length
Fiber coating
・With use of the fiber cleaver (FC-5S), a cleave length of 5-20mm is available
(forφ0.25mm coating dia.) Please check the manual of fiber cleaver (FC-5S) for
further detailed procedures.
To Next Page
