2-17
Take care to keep the spliced fiber straight. Do not flex it back and
forth. Doing so will cause the spliced fiber to be broken, resulting in
loss of the long term reliability of the fiber.
Remove the spliced fiber when
the screen above is displayed.
The proof test is automatically
started.(The test cannot be can-
celed once started.)
Open the hood.
Proof test
Press SET
key.
(if manual proof test is selected)
(if automatic proof test is selected)
3/3
To Next Page
