6-9
<Operation settings> (Administrator mode)
Operation Settings Details
Arc Pause Stops the splicing process temporarily before arcing. If you would like
to check fiber offset and fiber end faces during the process, set this
function to ON.
Re-align After Arc
Pause
Fibers are aligned again prior to splicing after Arc Pause.
Auto Start Automatically starts the splicing process when the fiber is inserted in
the splicer and the hood is closed.
Heater Auto Start Automatically starts the heating process when the fiber is placed into
the heat shrink oven.
Add Arc
Additional arc is available by setting this function to ON. If an arc is
insufficient, an additional arc should be performed.
Add Arc Setting
Allows to adjust the arc power for additional arc.
Ignore Cleave Angle
Limit
If this item is set to ON, the splicer will ignore a result of cleave angle
inspection. The default is OFF.
Ignore Cleave Errors If this item is set to ON, the splicer will ignore a result of cleaving
quality inspection. The default is OFF.
Ignore Post-Fusion
Check Error
If this item is set to ON, the splicer will ignore a result of post-fusion
inspection. The default is OFF.
Fiber Insertion Screen Single (X or Y) screen type or dual (X and Y) screen type can be se-
lected in each step of the splicing process.→ For further information,
please refer to the next page.
Pre-Fusion Screen
Arc Screen
Post-Fusion Screen
Est. Loss Screen
Postsplice Action
(Proof-Reset)
Allows to select an action to be done after splicing, i.e. a proof test is
carried out or not, and resetting is automatically performed or not.
Information Dialog
Settings
Enables/disables display of a popup information screen.
