Chapter 6 First-Time Configuration 6-13
6.1.7.1 Sun StorEdge 3510 FC Array
TABLE 6-2 contains the maximum number of disks that the Sun StorEdge 3510 FC
array can support in a logical drive.
TABLE 6-3 contains the maximum usable capacity
of a Sun StorEdge 3510 FC array logical drive.
Note – You can have a maximum of eight logical drives. The Sun StorEdge 3510 FC
array supports a maximum of 108 logical drives (one array and eight expansion
units).
Note – In some configurations, you might not be able to use all disks for data when
using 108 146-Gbyte disks. Any remaining disks can be used as spares.
6.1.7.2 Sun StorEdge 3511 FC Array
TABLE 6-4 contains the maximum number of disks per Sun StorEdge 3511 FC array
logical drive.
TABLE 6-5 contains the maximum usable capacity of a logical drive.
Note – You can have a maximum of eight logical drives. The Sun StorEdge 3511 FC
array supports a maximum of 64 disks for storage with an additional 8 disks for
spares, for a total of 72 disks (one array and five expansion units).
TABLE 6-2 Maximum Number of Disks per Sun StorEdge 3510 FC Array Logical Drive
Disk Capaci-
ty (GB)
RAID 5
Random
RAID 5 Se-
quential
RAID 3
Random
RAID 3 Se-
quential
RAID 1
Random
RAID 1 Se-
quential
RAID 0
Random
RAID 0 Se-
quential
36.2 14 31 14 31 28 36 14 36
73.4 7 28 7 28 12 30 6 27
146.8 4 14 4 14 6 26 3 13
TABLE 6-3 Maximum Usable Capacity (Gbyte) per Sun StorEdge 3510 FC Array Logical Drive
Disk Capacity RAID 5
Random
RAID 5 Se-
quential
RAID 3
Random
RAID 3 Se-
quential
RAID 1
Random
RAID 1 Se-
quential
RAID 0
Random
RAID 0 Se-
quential
36.2 471 1086 471 1086 507 543 507 1122
73.4 440 1982 440 1982 440 1101 440 1982
146.8 440 1908 440 1908 440 1908 440 1908
