4-2 Sun StorEdge 3000 Family Installation, Operation, and Service Manual • May 2004
Caution – When positioning the array, do not block the air vents at the front or back
of the unit. Follow all safety precautions specified in the Sun StorEdge 3000 Family
Safety, Regulatory, and Compliance Manual.
Caution – When you power off an array, wait five seconds before you power it back
on. If you power the array off and on too quickly, unexpected results can occur. See
“Power-Off Procedure” on page 4-30.
4.1 Converting Your Front Bezel Locks So
the Keys Cannot Be Removed
The bezel on your array has two locks whose keys can be removed when the locks
are in either the locked or open position. It is possible to reconfigure the locks so that
the keys cannot be removed.
FIGURE 4-1 Front Bezel and Front Bezel Locks of an Array
To change the locks so the keys cannot be removed, perform the following steps:
1. Remove the bezel by gently pivoting the swing arms out of their ear sockets.
See “Removing the Front Bezel and Ear Caps” on page 8-26 for step-by-step
instructions on how to remove the bezel.
2. Make sure the key is in the locked position, with the pawl extending horizontally
past the edge of the bezel.
3. Hold the key in place and use a 12 mm or 3/8-inch nut driver to remove the
locking nut that holds the pawl in place, as shown in the first panel of
FIGURE 4-2.
Bezel locks
