1-4 Sun StorEdge 3000 Family Installation, Operation, and Service Manual • May 2004
RAID or JBOD/Expansion Unit Identification on Chassis. A label on the bottom lip
of an array chassis, underneath the front bezel, indicates whether it is a JBOD array
or a RAID array. For instance, “3510 AC JBOD” refers to an alternating-current
version of a 3510 JBOD array, “3510 DC JBOD” refers to a direct-current version of a
JBOD array, and “3510 AC RAID” refers to an alternating-current version of a RAID
array. Similarly, using a UNIX command such as probe-scsi-all provides similar
TABLE 1-2 Sun StorEdge 3510 and 3511 FC Array Configuration Options
Internal RAID controllers Up to 2, with a minimum of 1
2-Gbit/sec Fibre Channel disks
(Sun StorEdge 3510 FC Array)
*
1.5-Gbit/sec serial ATA disks
(Sun StorEdge 3511 FC array)
* 1-GHz drives are not supported.
Up to 12 per array or per expansion unit, with a
minimum of 4 plus 1 spare
FC expansion units
†
† A disk array with no controller. Each expansion unit has two Fibre Channel loops that can provide redundant
data paths back to the RAID array.
Up to 8 for a Sun StorEdge 3510 FC array. Up to 5 for a
Sun StorEdge 3511 FC array
FC JBOD arrays
‡
(Sun
StorEdge 3510 FC array only)
‡ A disk array with no controller that is connected directly to a host computer, with no RAID array in the loop.
Only Sun StorEdge 3510 support the JBOD configuration.
1
Connection options • Serial port
• Ethernet
• Fibre Channel Small Form-Factor Pluggable (SFP)
Supported RAID levels 0, 1, 3, 5, 1+0, 3+0, and 5+0
Redundant field-replaceable
units (FRUs)
• Power supply and fan modules
• I/O controller modules and I/O expansion modules
• I/O expansion modules
• Battery board module
• Disk drive modules
Configuration management and
enclosure event reporting
options
§
§ The host-based Sun StorEdge Configuration Service software provides a graphical user interface (GUI) and ad-
ditional event-reporting capabilities.
• In-band Fibre Channel ports
• Out-of-band 10/100 BASE-T Ethernet port
• RS-232 connectivity
• Enclosure monitoring by SCSI Enclosure Services
(SES)
