Chapter 3: Maintenance and Component Installation
Figure 3-1. Removing the Left-side Cover
3.2 Accessing the System
Except for short periods of time, do not operate the workstation without the cover in place.

Left Side and Right Side Covers
Removing the Left Side Chassis Cover

1. Using a screwdriver, remove the two screws at the rear of the chassis.
Push the release button located at the top rear of the chassis as shown below.
Lift the cover up to remove it from the chassis.
2
1
3
