60
Chapter 3: Maintenance and Component Installation
3.9 Expansion Cards

Figure 3-18. Expansion Card Chassis Slots
Expansion Slot Locations
Item Description
6 
5 PCIe 5.0 x16 full-height, 10.5" slot (CPU1)
4 
3 PCIe 5.0 x16 full-height, 10.5" slot (CPU1)
2 
1 PCIe 5.0 x16 full-height, 10.5" slot (CPU1)
5
1
3
4
2
6
