Supermicro SuperWorkstation SYS-751A-I - Front Side Drive Bays

51
Chapter 3: Maintenance and Component Installation
Figure 3-9. Installing Front Side Drives
Front Side Drive Bays

not hot-swap, power must be removed from the system before removing or installing drives.
Installing/Removing the Front Side Drive Bays
powering down the system.
1. Push the release tab on either of the two drive bays so that the drive tray pops out from
the chassis.
Pull the drive tray out and install drives as needed. See the next section.
Push the drive tray and drive back into the bay and attach the wiring.
4. To remove drives from these bays, disconnect their wiring before pulling the tray from
the chassis.
1
2
