Chapter 3: Maintenance and Component Installation
Installing the Fan onto the Heatsink
1. Align the aluminum fan shroud against the top of the heatsink. The fan shroud is
designed to match with the top of the heatsink in terms of geometric shape.
Push the fan onto the heatsink until the bottom of the fan rests on the two hooks of the
heatsink.

