SUPVAN Chapter 3 Consumable Installation
14
Chapter 3 Consumable Installation
As an equipment manufacturer, Supvan can provide only four major
categories of consumable media including ribbon, label, tube, and cutter
group. For other consumable media, please contact with your supplier.
3.1 Installation and Removal of Ribbon Cassette
3.1.1 Installation
(1) See Figure 1. Tighten the ribbon according to the direction of arrow on
ribbon cassette.
(2) Put the print head in a non-printable position.
(3) See Figure 2. Place the ribbon cassette at the position marked on
tube printer.
Figure 1 Tighten the Ribbon
Figure 2 Ribbon Cassette Installation
3.1.2 Removal
(1) Make the print head in a non-printable position.
(2) Press the clamping tongue inward with a finger to lift it upward so as
to remove the ribbon cassette easily according to the direction of
arrow in the following figure.
Removal of Ribbon Cassette
