Supvan TP76E - Installation and Removal of Label Cassette

SUPVAN Chapter 3 Consumable Installation
15
3.2 Installation and Removal of Label Cassette
3.2.1 Installation
(1) Open the upper cover.
Please pull the label about 2cm out of the outlet of label cassette. See
the following figure.
(2) Align the tabs on the label cassette with the holes in the printer, and
then push the label cassette in until it clicks into the place.
(3) Ensure the front end of label exits the pinch roller.
Note:
 Please ensure that the clamping tongue in the left of label cassette
has been returned.
(4) Close the upper cover.
3.2.2 Removal
(1) Open the upper cover.
Printing
media
2 cm
Clamping tongue
