SUPVAN Chapter 3 Consumable Installation
16
(2) Make the print head in a non-printable state.
(3) Press the clamping tongue in the left of label cassette and lift upward
the cassette at the same time.
(4) Close the upper cover.
Note:
 Do not store any label cassette under the following conditions:
① Dirty and dusty place;
② Any place with direct sunlight;
③ Hot or humid place;
④ Any place that the temperature is lower than -25℃ or higher than
120℃
3.2.3 Label installation location
For any label installation location, see the following figure. Pull the head of
label to a lower position of main rubber-covered roller.
3.3 Installation and Removal of Tube Adjuster and Tube
3.3.1 Installation of tube
Install a tube into tube adjuster.
Main rubber-covered
roller
Label
