396-4412Y1 QuickDraw 3000 Operator’s Manual 18 Revised 02/20/2020
A batch will not run if there is an alarm. The issue must be resolved before the batch can be started or
resumed.
Product Valve X Failed to Open
Product Valve X Failed to Close
Product X Flow Failure—Check Product in Tote, valves open. New tote may need Prime Enabled.
Carrier Flow Failure
Batch Complete, Products Not Complete—Not all chemicals were added to batch.
Battery Voltage Low—Charge battery. Use good battery in QD cabinet.
ESTOP has been enabled. Disable ESTOP to return to normal operation.
Mass Meter Comm Loss—See Troubleshooting section, number 1 and number 12.
CANNOT DUPLICATE A LOAD ORDER
CANNOT SKIP A LOAD ORDER
Suction Only
Carrier Throttling Valve Failed to Open
Carrier Throttling Valve Failed to Close
Multi Carrier Only
Carrier Valve X Failed to Open
Carrier Valve X Failed to Close
TOTAL CARRIER VOLUME HAS NOT BEEN ALLOCATED
MORE CARRIER HAS BEEN ALLOCATED THAN IS IN THE RECIPE
Can Not Have Duplicate Load Orders in Carrier Setup
Can Not Skip a Load Order in Carrier Setup
Carrier to be used as Preload has not been selected
Carrier Selected for Preload has no Rate and/or Load Order
Preload is larger than the total amount for the selected Carrier
Carrier must have a Rate if it has a Load Order
A Carrier must be selected if it has a Load Order
See Troubleshooting section of this manual.
See support.surefireag.com website.
Alarms
Be sure valve is plugged in with good connection.
Go to RUN > Manual Controls > open/close valve.
Check Valve Position on Manual Controls screen.
