396-4412Y1 QuickDraw 3000 Operator’s Manual 19 Revised 02/20/2020
Warnings
A batch will run if there is a Warning, but the issue should be looked at as it could lead to a more
serious problem. The warnings related to how much product is available are dependent on the
inventory level being set correctly when a tote is attached. Be sure that the inventory level reported on
the QuickDraw matches what is actually in the tote.
Carrier Level is Below the Low Level Setpoint
Product X Level is Below the Low Level Setpoint
Carrier Level is Below What is Needed to Complete the Batch
Product X Level is Below What is Needed to Complete the Batch
Some Automated Products are Set to Batch Less than 0.5 Gal. This may affect accuracy.
PreLoad Too Large for Batch Size—Reduce PreLoad amount for Batch.
Some Products have a Load Order and Rate but no Selected Product.
Some Products have Rates but No Load Order
Air Detected In Mass Meter
Excessive Air In Mass Meter
The Hose Volume for at least one of the Totes is Larger than the Batch Total for that Tote
Some Carriers Have Rates but No Load Order
Some Carriers are Set to Batch Less than 20 Gal. This May Affect Accuracy.
Carrier Volume May be Too Low to Guarantee Batch Success due to Carrier Calibration.
After Preload, more than 65% of the batch needs to be Carrier to Guarantee Batch Success
May be an issue when App Rate is very low and chemical concentration is high.
Carrier Calibration is not possible due to Low Carrier Setpoint.
Carrier Failed to Calibrate
MultiCarrier Only
Carrier X Level is Below the Low Level Setpoint
Carrier X Level is Below What is Needed to Complete the Batch
Carrier X Calibration is not possible due to Low Carrier Setpoint.
Carrier X Failed to Calibrate
See Troubleshooting section of this manual.
See support.surefireag.com website.
Check the product level in
the tote.
Check the Inventory Level
for that product in QD.
If tote is low, can empty
tote, PAUSE batch, hook up
new tote, and RESUME.
Tighten all fittings and clamps from Tote to Mass Meter on QD.
This could also happen when a new tote is connected or when a
tote is near empty.
Check the carrier level in the
tank.
Check the Inventory Level for
that carrier in QD.
To Next Page
