4.5.1.8. Connector on Distribution Board (JP, X)
4.5.1.9. Connector on Mains Box (X)
4.5.1.10. Switch (Q,S)
Identifier Function
JP1 Service PLC Jumper
JP2 K1 nc / no select
X1 PLC base unit (OD232 module)
X2 Valve block I
X3 Valve block II
X4 Power PLC
X5 Board connector
X6 PLC analog output (AD081)
X7 PLC module digital in (ID211)
X8 Interlock nitrogen CIC1200
X9 Buzzer
X10 Splitter box for camera selection left / right
Identifier Function
X11 Power supply 100 - 240 V/AC
X12 Connector mains box
X13 Earthed socket lamp power supply 100 - 240 V/AC
X14 Earthed socket ext. additional 100 - 240 V/AC
X15 Plug-in card U1
X16 Initiator cluster block U2
X17 Initiator cluster block U3
Identifier Function
Q1 Main Switch with emergency stop
2S2 Key electronic ON / OFF
