Suzuki Burgman AN400 Service Manual

1A-67 Engine General Information and Diagnosis:
Specifications
Service Data
B705H11107001
Injector
FI Sensors
Item Specification Note
Injector resistance Approx. 10.3 Ω at 20 °C (68 F°)—
Item Specification Note
CKP sensor resistance 190 – 290 Ω
CKP sensor peak voltage 4.5 V and more (When cranking)
(+) probe: G/W,
(–) probe: Bl
IAP sensor input voltage 4.5 – 5.5 V
IAP sensor output voltage Approx. 1.5 – 3.5 V at idle speed
TP sensor input voltage 4.5 – 5.5 V
TP sensor output voltage
Closed Approx. 0.6 V
Opened Approx. 3.8 V
ECT sensor input voltage 4.5 – 5.5 V
ECT sensor resistance Approx. 2.58 kΩ at 20 °C (68 °F)
IAT sensor input voltage 4.5 – 5.5 V
IAT sensor resistance Approx. 2.58 kΩ at 20 °C (68 °F)
TO sensor resistance 16.5 – 22.3 kΩ
TO sensor output voltage
Normal 0.4 – 1.4 V
Leaning 3.7 – 4.4 V
Injector voltage Battery voltage
Ignition coil primary peak voltage 150 V and more (When cranking)
(+) probe: W,
(–) probe: Ground
HO2 sensor resistance 11.5 – 14.5 Ω at 23 °C (73.4 °F)
HO2 sensor output voltage
Idle speed 0.3 V and less
3 000 r/min 0.7 V and more
STP sensor input voltage 4.5 – 5.5 V
STP sensor output voltage
Closed Approx. 0.5 V
Opened Approx. 3.9 V
STP actuator resistance Approx. 6.5 Ω

Suzuki Burgman AN400 Specifications

General

Engine Type	4-stroke, 1-cylinder, liquid-cooled, DOHC
Displacement	400cc
Bore x Stroke	81.0 mm x 77.6 mm
Fuel System	Fuel injection
Starter	Electric
Front Suspension	Telescopic, coil spring, oil damped
Front Brake	Disc, twin
Rear Brake	Disc
Front Tire	120/70-15M/C 56S, tubeless
Rear Tire	150/70-13M/C 64S, tubeless
Curb Weight	215 kg
Fuel Capacity	13.5 liters
Transmission	CVT
Width	765 mm
Seat Height	735 mm
Rear Suspension	Swingarm type, coil spring, oil damped
Length	2235 mm
Height	1350 mm
Wheelbase	1580 mm
