Suzuki Burgman AN400 Service Manual

Table of Contents 3- i
3
Section 3
CONTENTS
Driveline / Axle
Precautions .................................................3-1
Precautions............................................................. 3-1
Precautions for Driveline/Axle ............................... 3-1
Drive Chain / Drive Train / Drive Shaft... 3A-1
Diagnostic Information and Procedures............3A-1
Drive Chain and Sprocket Symptom
Diagnosis .......................................................... 3A-1
Repair Instructions ..............................................3A-2
Final Gear Components...................................... 3A-2
Final Gear Assembly Removal and
Installation .........................................................3A-3
Final Gear Disassembly and Assembly ..............3A-4
Final Drive Gear Bearing Inspection ...................3A-8
Specifications.......................................................3A-9
Tightening Torque Specifications........................3A-9
Special Tools and Equipment .............................3A-9
Recommended Service Material .........................3A-9
Special Tool ........................................................3A-9

Suzuki Burgman AN400 Specifications

General

Engine Type	4-stroke, 1-cylinder, liquid-cooled, DOHC
Displacement	400cc
Bore x Stroke	81.0 mm x 77.6 mm
Fuel System	Fuel injection
Starter	Electric
Front Suspension	Telescopic, coil spring, oil damped
Front Brake	Disc, twin
Rear Brake	Disc
Front Tire	120/70-15M/C 56S, tubeless
Rear Tire	150/70-13M/C 64S, tubeless
Curb Weight	215 kg
Fuel Capacity	13.5 liters
Transmission	CVT
Width	765 mm
Seat Height	735 mm
Rear Suspension	Swingarm type, coil spring, oil damped
Length	2235 mm
Height	1350 mm
Wheelbase	1580 mm
