Fuel System: 1G-5
Repair Instructions
Fuel System Components
B705H11706001
2
4
3
1
“a”
I705H1170040-01
1. Brake-lock cable 3. Check valve “a”: 5 mm (0.2 in)
2. Water drain hose 4. Breather hose
