. V-BELT DRIVE SYSTEM
9-1
Mechanism Diagram ··························· 9-1
Precautions in Operation···················· 9-2
Troubleshooting·································· 9-2
Left Crankcase Cover ························· 9-3
Drive Belt ··············································9-4
Drive Face·············································9-6
Clutch Outer / Driven Pulley················9-9
Mechanism Diagram
5.0~6.0kgf-m
3.5~4.5kgf-m
5.0~6.0kgf-m
