13. COOLING SYSTEM
13-12
Thermostat
Please refer to chapter 17 for inspection of
temperature sensor.
Removal
Remove the luggage box and body cover.
Drain out the coolant.
Disconnect the cable of temperature sensor.
Disconnect the by-pass pipe.
Remove the thermostat set. (1 bolt)
Installation
Apply a coat of sealant or equivalent to the thread
of temperature sensor and install it on the holder.
Connect the cable to the temperature sensor.
Refill the coolant and bleed out the air bubble
(Page 12-5).
Install the luggage box and body cover.
Disassembly
Remove the temperature sensor and O-ring from
the thermostat body.
Remove 2 bolts and separate the thermostat body
from the cover.
Remove the thermostat.
2 bolts
O-ring
Temperature sensor
Bolt
Temperature sensor
By-pass pipe
