Sym HD2 125 - Crankcase and Crankshaft Service

12. CRANKCASE / CRANKSHAFT
12-1
Mechanism Diagram ··························12-1
Precautions in Operation···················12-2
Troubleshooting·································12-2
Crankcase Disassembly···················· 12-3
Crankshaft Inspection ······················· 12-5
Crankcase Reassembly····················· 12-6
Mechanism Diagram
1.5~3.0kgf-m
1.0~1.5kgf-m
0.8~1.2kgf-m
1.2~1.6kgf-m
