Sym HD2 125 - Steering, Front Wheel, and Front Cushion

16. STEERING / FRONT WHEEL / FRONT CUSHION
16-1
Mechanism Diagram·························· 16-1
Precautions in Operation·················· 16-2
Troubleshooting ································ 16-2
Steering Handle ································· 16-3
Front Wheel ········································ 16-5
Front Cushion····································· 16-8
Steering Stem····································· 16-9
Mechanism Diagram
4.0~4.5kgf-m
4.0~5.0kgf-m
5.0~7.0kgf-m
0.2~0.3kgf-m
1.0~2.0kgf-m
