Sym HD2 125 - Electrical System; Mechanism Diagram and Precautions

18. ELECTRICAL SYSTEM
18-1
Mechanism Diagram ··························18-1
Precautions in Operation···················18-2
Technical Specification······················18-2
Troubleshooting·································18-3
Battery·················································18-4
Charging System································18-5
Ignition System···································18-8
Starting System··································18-9
Meters················································· 18-10
Light / Bulb········································· 18-11
Switch / Horn······································ 18-14
Fuel Unit············································· 18-17
Cooling Fan Thermo Switch ············· 18-18
Thermo Unit ······································· 18-19
Water Temperature Meter ················· 18-19
Mechanism Diagram
Winker relay
Spark plug
AC. Generator
Fuse box
Battery
Ignition coil
Fuel pump / Fuel unit
Main switch
ECU
Regulator rectifier
Starter relay
Horn
Headlight relay
Home page
Contents
18
Fuel pump relay
Thermo switch
O2 sensor
Thermo unit
TW sensor
Injector
MAP sensor
Power relay
TPS
AISV
ISC
TA sensor
Rollover sensor
