Sym HD2 125 - AC Generator and Start Clutch Service

11. AC. GENERATOR / START CLUTCH
11-1
Mechanism Diagram ··························11-1
Precautions in Operation···················11-2
Right Crankcase Cover Removal······11-3
ACG. Set Removal······························11-3
Flywheel Removal ······························11-3
Start Clutch·········································11-4
Flywheel Installation··························11-7
ACG. Set Installation ·························11-7
Right Crankcase Cover Installation··11-7
Mechanism Diagram
5.0~6.0kgf-m
1.0~1.4kgf-m
0.8~1.2kgf-m
