18. ELECTRICAL SYSTEM
18-10
Removal of Starter motor
Remove the battery cover (5 screws).
Disconnect the cable negative terminal (-), then
the cable positive terminal (+).
Remove the luggage box.
Remove the air cleaner.
Loosen the lock bolts and remove the starter
motor.
Installation of Starter motor
Install in reverse order of removal procedures.
Meters
Removal
Remove handle front cover.
Remove the front cover, and then remove meter
coupler and handle switch coupler.
Remove speedometer cable.
Remove handle rear cover and speedometer.
Loosen 3 screws, and then remove speedometer
from handle rear cover.
Installation of Starter motor
Install in reverse order of removal procedures.
To this chapter contents
2 Bolts
3 screws
Meter cable
