11. AC. GENERATOR / START CLUTCH
11-6
Remove 3 hexagon bolts with air and hex socket
wrenches.
Disassembly
Install the components in the reverse procedures
of removal.
Caution
Tape a tightening tape onto the thread of hexagon
bolt.
Torque value: 1.0~1.4kgf-m
Installation
Install reduction gear shaft and reduction gear.
Install starting clutch gear onto crankshaft.
