14. BODY COVER
14-8
Luggage Box
Remove
Open seat.
Loosen 4 nuts & 2 bolt of the luggage box.
Loosen 1 screw from front side of the body cover.
Remove the luggage box.
Installation
Install in reverse order of removal procedures.
4 nuts
2 bolts
1 screw
