14. BODY COVER
14-12
Floor Panel
Remove
Loosen 4 screws from the right & left step bar.
Remove the right & left step bar covers.
Loosen 2 screws from the right & left step bar, and
then remove step bars.
Remove the battery and CDI.
Loosen 4 bolts from the floor panel.
Remove the floor panel.
Installation
Install in reverse order of removal procedures.
4 screws
2 bolts
4 bolts
