18. ELECTRICAL SYSTEM
18-15
Dimmer and Passing switch
Pin
Position
HL LO HI PASS
PASSING
Wire color
Brown
/ White
White Blue
White /
Green
Winker switch
Pin
Position
R WR L
FROM R
PUSH OFF
N
FROM L
Wire color
Light
green
Gray Orange
Horn switch
Pin
Position
BAT3 HO
FREE
Wire Color White/ Green Light green
Dimmer and passing switch
Winker switch
Horn switch
Dimmer and passing switch
Winker switch
Horn switch
