Technical Specifications A-3
Mobile Computer Technical Specifications
The following table summarizes the mobile computer technical specifications and intended operating environment.
Table A-1. Mobile Computer Technical Specifications
Operating Temperature Color
14° to 122°F (-10° to +50°C)
Monochrome
-4° to 122°F (-20° to +50°C)
Storage Temperature -22° to 160°F (-30° to 70°C)
Battery Charging Temperature 32° to 104° F (0° to +40° C) ambient temperature
Humidity 5% to 95% non-condensing
Electrostatic Discharge (ESD) +/-15 kV air discharge
+/- 8 kV direct discharge
+/- 8 kV indirect discharge
Drop to Concrete 4 feet (1.2 meters)
Sealing IP54 category 2
Drop Multiple 4-foot (1.2 m) drops to concrete across operating temperature
Tumble 500 one -half meter tumbles at room temperature (1000 drops)
Dimensions
MC3000-K:
7.43 in L x 3.18 in W x 1.76 in D
(188.7 mm L x 80.8 mm W x 44.6 mm D)
MC3000-R:
8.33 in L x 3.18 in W x 1.57 in D
(211.6 mm L x 80.8 mm W x 39.9 mm D)
Weights MC3000-R (with standard battery)* - 12.9 oz (366 g)
MC3000-K (with extended battery)* - 14.6 oz (414 g)
*For WLAN mobile computers add approximately 0.5 oz (14 g).
Display Transflective color TFT-LCD, 65K colors, 324 x 324
Monochrome FSTN, 16 shades, 320 x 320
Touch Panel Glass, analog resistive touch
Main Battery Standard: Rechargeable Lithium-Polymer 2600 mAh minimum (3.7V)
Extended Life: Rechargeable Lithium-Ion 4400 mAh minimum (3.7V)
Backup Battery Ni-MH battery (rechargeable), 20mAh (3.6V) 3 cells
Operating Platform Microsoft
®
Windows CE .NET 4.2 Professional
Microsoft
®
Windows CE .NET 4.2 Core
Processor/Memory Intel
®
XScale™ PXA 312MHz with 32MB RAM/64MB Flash or
Intel
®
XScale™ PXA 520MHz with 64MB RAM/64MB Flash
Interface RS232, 115.2 kbps max, and USB
WLAN Symbol Spectrum 24, 802.11b, 802.11g
Keypad Options 28-Key, 38-Key and 48-Key
