Symbol MC3000 - Rotating Scan Turret

MC3000 Integrator Guide1-6
Figure 1-2. MC3000 Imager (MC3000-K) and MC3000 Laser (MC3000-R) Mobile Computers (back view)
Rotating Scan Turret
The MC3000-R mobile computer features a Rotating Scan Turret with three position stops. This feature offers greater scanning
flexiblilty.
Figure 1-3. Rotating Scan Turret
Strap/Door
Assembly
Scan Window
Stylus
MC3000-K
MC3000-R
Latches
Strap/Door
Assembly
Screws
Stylus
Holder
Headset Jack
(optional)
Headset Jack
(optional)
Scan Window
Position Stop
Position Stop
Position Stop
