MC3000 Integrator Guide6-12
10. If USB was selected in the Select Transport menu, the Waiting for Download message appears.
Figure 6-9. Waiting for Download
11. On the development computer, click Load on the TCM toolbar. The Load Terminal window - Serial tab appears.
Figure 6-10. Load Terminal Window - Serial and Ethernet Tabs
12. For serial or USB port connections, click the Serial tab and select the Image Files To Load.
The USB: Symbol Device option will not appear on the Comm Port drop-down list until after the Waiting for
Download message has completed.
13. Select the Serial or USB: Symbol Device from the Comm Port drop-down list.
14. For serial connections, select the Baud Rate from the from the Baud Rate drop-down list.
15. Click Download to begin the operation.
16. During download, the Downloading screen on mobile computer displays the Device Status and a progress bar.
Downloading . . . .
Auto Select
via USB USB standard
waiting for input . . . .
