SECTION V- MANUAL KEY OPERATIONS
36
NOTE:
Using Manual Issue Keys on all system types allows the selection of all
hoses configured on the unit since no product limitations are encoded on
the key.
NOTE:
An ‘*’ next to a hose number means that this hose is already in use. A
message to this effect will be displayed if this hose is selected.
Once a hose is selected, one of two messages appears on the FMU
display. These messages depend upon the type of dispenser in use and
how it was wired during installation of the FuelMaster® hardware:
This authorization prompt appears if the FMU configuration is set not to detect
the pump handle. It does not matter when the pump handle is turned on. When
this message appears, the FMU is ready to track fueling.
<<< TURN ON PUMP HANDLE TO DISPENSE >>>
<<< THE SELECTED PRODUCT >>>
This authorization prompt appears if the FMU configuration is set to Pump
Handle Detect. It indicates that the FMU is ready to watch for the pump handle to
be turned on. The prompt then indicates the dispenser hose status.
>>> DISPENSER HAS BEEN ACTIVATED <<<
>>> RETURN HOSE AFTER USER <<<
When the FMU sees the pump handle turned on, it responds with the above
message and is ready to track fueling.
** PUMP HANDLE NOT TURNED OFF ! **
** PLEASE TURN PUMP HANDLE OFF. **
If the above display appears, the pump handle selected was already in the ‘ON’
position at the time this handle was selected. To begin fueling with this pump
Mechanical dispenser
**TURN ON PUMP HANDLE TO DISPENSE
THE SELECTED PRODUCT**
Electronic dispenser
*** DISPENSER ENABLED ***
*** DISPENSE PRODUCT ***
