SECTION III- EITHER KEY OPERATIONS
26
This prompt requires that the ‘YES’ or ‘NO’ key on the FMU keypad be pressed
based on whether the oil has been checked at the time of this fueling transaction.
Press ‘YES’ or ‘NO’ and the following prompt will display:
***** FUELMASTER *****
ENTER OIL QTY ADDED (QUARTS) --->
This prompt requires entry of a single digit between 0 and 9 on the FMU keypad.
Enter the number of quarts of oil added at the time of this transaction and press
<ENTER>. (To enter a 2 digit number contact Syn-Tech Systems, Inc. product
support for details.)
NOTE:
The oil check transaction will appear as a separate transaction on the FMU’s on-
site printer and in the Central Controller’s transaction listing but will appear at the
bottom of the fuel transaction receipt on the FMU’s receipt printer. This feature is
provided as an additional record keeping capability of FuelMaster systems.
BOTH KEYS SYSTEM PROCEDURES
After entries have been made and validated, the following hose selection
display appears:
REMOVE KEY, SELECT HOSE, PRESS <ENTER>
1, 2, 3, 4, 5, 6, 7, 8 --->
The selection is limited to those hoses with the same product code(s) as the
authorized vehicle or User Key. Select the hose of choice and press
ENTER/YES.
NOTE:
An ‘*’ next to a hose number indicates that this hose is already in use. A
message to this effect will be displayed if this hose is selected.
Once a hose is selected, one of two messages appears on the FMU
display. These messages depend upon the type of dispenser installed and
how it was wired during installation of the FuelMaster® hardware:
Electronic dispenser
*** DISPENSER ENABLED ***
*** DISPENSE PRODUCT ***
Mechanical dispenser
**TURN ON PUMP HANDLE TO DISPENSE
THE SELECTED PRODUCT**
