SECTION VII - SUPERVISOR KEY ACCESS
53
• MM - The 8-1 line corresponds with PUMP H-A. A 0 below the
pump number means the switch is in AUTO. When toggled to
manual, the 0 changes to a 1.
CONFIG > TESTS > OUTS (OUTPUTS)
When selected, the LEDs on the relay board blink starting with location
K1. The relay board is located in the FMU pedestal above the manual
mode switches. Only LEDs corresponding to an existing relay blink. This
test determines if relays in the relay board are bad, by switching them off
and on.
CONFIG > TESTS > LCD
The LCD test checks the integrity of the display board. When selected,
black boxes appear in the first row and strobe to the second. If any of the
LCD pixels are bad, the black box appears lighter than the rest.
CONFIG > TESTS > KEYPAD
The prompt requests keypad key presses for verification. The keypad
should display the number or letter selected. If a number or letter is
repeated, the selected number or letter will appear as repeated characters
on the LCD until the row is full or until a different number or letter is
pressed. The CLEAR/NO and ENTER/YES keys should respond with an
‘N’ and ‘Y’ respectively.
CONFIG > TESTS > RECEIPT
This triggers the pedestal receipt printer (if equipped) to print a receipt,
testing communication between FMU and printer.
CONFIG > TESTS > BOARDS
This displays the boards detected by the FMU during boot up to make you
aware of installed boards in the FMU.
CONFIG > TESTS > PROKEE®
This test displays information read from a ProKee® in various formats,
selectable from the menu shown below.
PROKEE DISPLAY FORMAT: 1=FIELDS, A=ASCII
B=HEX, C=SHOW PIN, D=EXIT
