Note
Note
Please ensure to use as much of the available thread length as possible for tightening the Node to
Please ensure to use as much of the available thread length as possible for tightening the Node to
prevent damage to the thread.
prevent damage to the thread.
1.3.2.4 Interference with magnetic fields
Please consider the placement of the servo drive carefully when designing the motion control
application. It has become evident that the motor’s magnetic field has an impact on the servo drive’s
performance.
Attention
Attention
Please also consider the magnetic fields that emenate from the brake.
Please also consider the magnetic fields that emenate from the brake.
These are the preferred arrangements:
1. At any position but shielded with a Faraday’s cage
2. Behind the motor
