1.1.2 General specifications
General specifications
Supported Communication
Standard
EtherCAT
Number of Phases 4
Supported Motors 1 x 3-phase BLDC-Motor and 1 active brake
Up to 2 Brushed DC Motors
[1]
Brake control voltage 0-48 V PWM Phase D
Analog Inputs 4 (2 x single-ended 0-10V, 2 x differential ±5V)
[2]
Digital IOs 4 × GPIO / SPI
[3]
/ I C
[3]
(3.3 V CMOS logic)
[4]
Encoder Connectors 2 x 4ch. RS-422
Supported Standard Encoder
Interfaces
Incremental Encoder (ABI), HALL, BiSS-C, SSI, SPI
[3]
, I C
[3]
Supported Encoder Types Encoder Port 1
Incremental Encoder (ABI),
BiSS-C, SSI, Half-Duplex, A-
Format
Encoder Port 2
Incremental Encoder (ABI), HALL,
BiSS-C, SSI, I C
[3]
Incremental Encoder max
frequency
1.4 MHz
[5]
(supports up to 14,000 rpm with a 4,096 resolution
incremental encoder)
Hardware Protections Overcurrent, Overvoltage, Undervoltage, Temperature
Compliance with standards CISPR 11 Class B
IEC 61000-4-6
IEC 61000-4-3
IEC 61000-4-2
IEC 61000-4-8
Dimensions 70 x 40 x 23 mm
Weight 85 g (incl. Heatsink)
Operating temperature 0 °C
[6]
to 40 °C
Storage Temperature -35 to 85 °C
Max. installation altitude 2000 m
Humidity 5-85% rH
Sensors on-board DC-BUS Voltage, DC-BUS current, Phase Voltage, Phase current
(two phases measured, one computed), Temperature
[1] Currently not supported by our standard software. Can be developed upon request, please
contact sales@synapticon.com
