1.4 LED signals
1.4.1 Overview
SOMANET Node has several LEDs that show the servo drive’s state or indicate errors.
1.4.1.1 Legend
Symbol Explanation
Off
Constantly luminous
Single flashes (1 pulse per second)
Slow blinking (3 pulses per second)
Fast blinking (10 pulses per second)
